Working area - 2460 x 1240 mm
Z- Gantry clearance - 300 mm
Total size of machine - 3000 x1600 x 1500mm
Double motorized-Stepper motors on all axes (Leadshine)
Electronic assembly - Leadshine stepper drives for all axis
25mm rack and pinion
20 mm high precision linear guides on X ,Y axes
Backlash free precision hardened and ground ball screw on Z-axis
Spindle 3 ,3.2Kw 0 - 18000/24000 rpm, (Air / Water Cooled)
Spindle control(VFD) - Best/Sunfar
Rapid transverse speed 20 meter/minute
Max working speed 18 meter/minute
Operating System - DSP (A1X)
Working area - 2480 x 1260 mm.
Z- Gantry clearance - 300 mm.
Total size of machine - 3000 x1800 x 1500 mm.
Double motorized-Servo motors on all axes - LEADSHINE EASY SERVO.
Electronic assembly - Servo drives for all axis - LEADSHINE EASY SERVO .
25mm rack and pinion.
20 mm high precision linear guides on X ,Y axes .
Backlash free precision hardened and ground ball screw on Z-axis 25mm.
Spindle 3,3.2Kw 0 - 18000/24000 rpm - Air/Water cooled
Spindle control(VFD) - Best/Sunfar/Fuling.
Rapid transverse speed 40 meter/minute.
Max working speed 30 meter/minute.
Operating System - DSP(A1X)
Working area - 2480x1260 mm.
Total size of machine - 3200x1600x1500 mm.
Z - Gantry clearance - 300 mm.
Double motorized-Stepper motors on all axes-Tamagawa Japan.
Electronic assembly - Stepper drives for all axis - RTA Italy.
25mm rack and pinion - YYC Taiwan / Tobaki.
20 mm high precision linear guides on X ,Y axes - Hiwin / Tobaki.
Backlash free precision hardened and ground ball screw on Z-axis.
25 mm Hiwin / Tobaki.
Spindle 3 , 3.2 Kw -0-18000 / 24000 rpm - HSD Italy.
Spindle control(VFD)-Yaskawa Japan /Allen Bradley USA.
Rapid transverse speed 28 meter/minute
Max working Speed 24 meter/Minute
Operating System - RADONIX with Windows operating system, P C based software from TURKEY.
Working area - 2480 x 1260 mm
Total size of machine - 3200 x 1600 x 1600 mm
Z - Gantry clearance - 300 mm
Double motorized-Servo motors 450W on X,Y axis - Leadshine, 750W break motor on Z axis - Leadshine
Driver boards-Leadshine.
25mm rack and pinion.
20 mm high precision linear guides on X ,Y axes.
Backlash free precision hardened and ground ball screw on Z-axis
Spindle 3.2 KW 0- 24000 rpm, (Water/AIR Cooled)
VFD(INVERTER) - Best / Sunfar / Fuling.
Rapid transverse speed 40 Meter/minute
Max working speed 30 meter/Minute
Operating System - DSP (NK105)
Working area - 2480x1260 mm .
Total size of machine - 3200x1600x1500 mm
Z- Gantry clearance - 300 mm
Double motorized-Servo motors 750W on all axis - FUJI - Japan, 750W break motor on Z axis - FUJI - Japan.
Electronic assembly - driver boards-FUJI - Japan.
25mm rack and pinion - YYC Taiwan / Tobaki , and planetary gear box; BONFIGLIOLI Italy.
25 mm high precision linear guides on X ,Y axes - Hiwin / Tobaki.
Backlash free precision hardened and ground ball screw on Z-axis;
25 mm Hiwin / Tobaki.
Spindle 3, 3.2 Kw 0 - 18000/ 24000 rpm, - HSD Italy.
Spindle control (VFD) - Yaskawa-Japan / Allen Bradley - USA.
Rapid transverse speed 50 Meter/minute
Max working Speed 40 meter/Minute
Operating System - DSP (NK105)
